For vertical lifting and transporting without marking of products with parallel sides in various materials as steel, wood, plastic, concrete, marble etc. The clamp is locked in the open position. To perform lifting, the operator must activate the handle and hold it up while the force on the lifting eye is going upwards. When laying down the load, the clamp automatically locks itself open. The pads are covered with special plastic to avoid damaging of the load.
type | Cap | Jaw | Dimensions in mm | wt | |||||
kgs | A | B | C | D | E | F | G | kgs | |
0.25 TBLC | 250 | 0-120 | 320-360 | 150-450 | 30 | 140-150 | 70*80 | 15 | 3 |
0.5 TBLC | 500 | 0-120 | 320-360 | 150-450 | 30 | 149-150 | 100*120 | 15 | 6 |
1 TBLC | 1000 | 0-250 | 510-660 | 350-530 | 45 | 180-220 | 100*120 | 17 | 9 |
1.5 TBLC | 1500 | 0-500 | 600-825 | 600-1200 | 65 | 250-300 | 100*120 | 20 | 10 |
2 TBLC | 2000 | 0-250 | 510-550 | 350-550 | 45 | 180-220 | 100*120 | 17 | 16 |
3 TBLC | 3000 | 0-500 | 600-825 | 600-1200 | 65 | 250-300 | 100*120 | 20 | 20 |
